Professional load cell sensor supplier, your reliable partner.
9 Years
| Ask Lasest Price | |
| Brand Name : | JULIXING |
| Model Number : | CFBPG |
| Certification : | CE and RoHS approval |
| Price : | Contacts us |
| Payment Terms : | T/T, Western Union |
Product Description
Category: Pressure Transmitter
Range: -0.1 KPa ~ 0 ~ 0.01 KPa ~ 100 MPa
Application: Widely used in metallurgy, thermal engineering, national defense,
scientific research, petroleum exploration and other departments of
the hydraulic and start-up equipment, industrial process control.
Dimensions in millimetres
| Specification | Value |
| Measuring Dielectric | Various liquids, gases or vapors compatible with 316 stainless steel. |
| Measuring Range | -0.1 KPa ~ 0 ~ 0.01 KPa ~ 100 MPa |
| Overload | 1.5 times the full-scale pressure or 110 MPa (take the minimum) |
| Voltage type | Gauge pressure, absolute pressure, sealed reference pressure. |
| Power supply | 15~30VDC / 15~25VDC / 15~28VDC |
| Output signal | 4~20mADC / 0~10/20mADC / 0/1~5/10VDC |
| Transmission mode | 2 wire / 3 wire / 3 wire |
| Accuracy | ±0.25%F·S / Max:±0.25%F·S Including non-linearity, hysteresis and repeatability |
| Long-term stability | Prototype: ± 0.1%F·S / Max: ± 0.2%F·S |
| Zero temperature coefficient | 0.03%F·S/℃ (≤100 KPa) / 0.02%F·S/℃(>100 KPa) |
| Working temp | -30~150℃ |
| Storage temp | -40~200℃ |
| Load resistance | ≤(U-15)/0.2Ω |
| Electrical connection | Cable connection, air plug, Hessman plug-in |
| Case materials | Stainless steel 1Cr18Ni9Ti |
| Procedural interface | M12×1; M20×1.5 or G1/4 external thread |
| Level of protection | IP65 |
| Explosion-proof sign | Exia Ⅱ CT6 |
| ● Company Introduction |
|---|
HK LEE HING
INDUSTRY CO., LIMITED is one of the leading suppliers of Load
Cells, indicators, scales and weight handling equipment in china, For
recent few years, we have been expanding business to more than 100
countries and areas, where we have built-up a good reputation for
super quality &fine image.
Strictly according to OIML R60, we design, manufacture and
distribute various load cells , indicators and scales to oversea
market with high precision reliable capability. Widely handled in
weighing for commerce, medical treatment, and industry. Our R&D
team is dedicated to exploring advanced weighing and electronic
technology, who is famous for high technical level great ability
creation. we develop new products that make use of the latest
weighing and electronic technology against customer's requirement.
As an experienced supplier of international companies' OEM and ODM
we take delight in providing complete technology solutions, under
this situation, we have been keeping healthy relation with many
Multinational Corporations.
HK LEE HING INDUSTRY CO., LIMITED. Your Business Solution. If you
have any interest , please don't hesitate to contact with us, you
will be assured that our professional service will make a
convenience of your needs.
We would appreciate your comments on the layout design,
presentation or other aspects of our website.
Please click: http://www.chinaloadcell.com/
| ● Contact Introduction |
|---|
Contacts: Kevin Huang
E-mail: sales@chinaloadcell.com
TEL: +86-755-33168386
FAX: +86-755-61605199
SKYPE: carlisle.wyk
Address: 1F Junfeng Building, Gongle, Xixiang, Baoan District, Shenzhen,
Guangdong, China
ZIP: 518102
Website: http://www.chinaloadcell.com
|
|
