Product Description
Category: Pull Pressure Load Cell
Range: Min 200kg; Max 100t.
Dimensions in millimetres
| RANGE | ΦA | ΦB | ΦC | M | H | H1 | H2 | ΦD | ΦC |
| 200 ~ 700 kg | 88 | 72 | 22 | M12 × 1.75 | 34 | 31 | 7.2 | 8 - Φ11 | 8 - Φ7 |
| 1 ~ 5 t | 105 | 89 | 32 | M16 × 1.5 | 37 | 34 | 7.2 | 8 - Φ11 | 8 - Φ7 |
| 10 ~ 20 t | 120.6 | 101.8 | 39 | M32 × 1.5 | 53.5 | 41 | 10.5 | 8 - Φ14 | 8 - Φ9 |
| 30 t | 141 | 116.8 | 50.4 | M40 × 1.5 | 57.2 | 50.8 | 11 | 8 - Φ18 | 8 - Φ11 |
| RANGE | ΦA | ΦB | ΦC | M | H | H2 | ΦD | ΦD1 |
| 40 t ~ 60 t | 208 | 174 | 95 | M64 × 3 | 70 | 15 | 16 - Φ20 | 16 - Φ13 |
| 80 t ~ 100 t | 280 | 230 | 120 | M76 × 3 | 90 | 20 | 16 - Φ30 | 16 - Φ17 |
| Specification | Unit | Value |
| Output Sensitivity | m V / V | 2.0 ± 0.05 |
| Non-linearity | ≤ % F.S | ± 0.03 |
| Hysteresis | ≤ % F.S | ± 0.03 |
| Repeatability | ≤ % F.S | ± 0.03 |
| Creep | ≤ % F.S / 30 min | ± 0.03 |
| Zero Balance | ≤ % F.S | ± 1 |
| Temp Effect on Zero | ≤ % F.S / 10 ℃ | ± 0.03 |
| Temp Effect on Span | ≤ % F.S / 10 ℃ | ± 0.03 |
| Use Temperature | ℃ | -20 ℃ ~ + 80 ℃ |
| Input Resistance | Ω | 750 ± 20 Ω |
| Output Resistance | Ω | 700 ± 5 Ω |
| Safe Overload | ≤ % F.S | 150 % F.S |
| Insulation Resistance | M Ω | ≥ 5000 M Ω ( 50 VDC ) |
| Excitation Voltage | V | 10 V ~ 15 V |
